| FRAME |
Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery with integrated alloy cover, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable |
| SIZES |
S: 380mm / M: 420mm / L: 450mm / XL: 490mm |
| REAR SHOCK |
Fox Float-X LV Performance, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings |
| SHOCK SETTINGS |
Medium compression, medium rebound, air volume spacer 0.2 |
| FORK |
Fox 38 29 Float FIT GRIP EVOL Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload |
| HEADSET |
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45°x45°, bottom 51.9x40x8x45°x45° |
| STEM |
Onoff Sulfur FG 30mm 0°, 6061 forged alloy, 31.8mm barbore |
| HANDLEBAR |
Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9° backsweep, 5° upsweep, 31.8mm barbore |
| GRIPS |
Onoff Diamond, 1lock-on, 135mm |
| SEAT POST |
Onoff Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm |
| SADDLE |
Fizik Terra Aidon X5 145mm |
| FRONT BRAKE |
Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| REAR BRAKE |
Sram G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| BRAKE LEVER |
Sram G2 R, tool-free reach adjust |
| RIMS |
Mavic E-Deemax 29, 30mm internal width, welded aluminum, PFP, tubeless ready, 28 spokes |
| SPOKES |
Mavic, steel double butted, contactless lacing |
| FRONT HUB |
Mavic, Boost 15x110mm, IS 6 bolts |
| REAR HUB |
Mavic, Boost 12x148mm, ID360 ratchet system, IS 6 bolts |
| FRONT TIRE |
Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead |
| REAR TIRE |
Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead |
| CRANKSET |
Race Face Aeffect ebike, 165mm |
| RINGS |
Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD |
| CHAIN |
Sram SX Eagle, 12s, Powerlock |
| REAR DERRAILLEUR |
Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
| SHIFT LEVERS |
Sram Trigger NX Eagle, 12s, X-Actuation 1:1, single click |
| CASSETTE |
Sram PG-1210, 11-50T, 12s |
| MOTOR |
Bosch Performance Line CX Cruise (25Km/h) |
| BATTERY |
Bosch Powertube 625Wh |
| DISPLAY |
보쉬 퓨리온 |
| DERAILLEUR HANGER |
Mondraker M068 |
| WEIGHT |
25.6 kg |
